Info |
Product
Name : PTC Creo ADVANCE
Downloadable File
Size : 1.25 GB
File Type : RAR File
Time of Education : 190
min |
FEM Analysis
and Simulation |
FEM Analysis
and Simulation:
LOADS
force – moment – pressure – bearing –
gravity – temperature
CONSTRAINT
displacement – planar – pin
MATERIAL ASSIGNMENT – CONNECTIONS
– interface connections – assembly analysis – Auto GEM
Analysis result – stress – strain –
displacement
MODAL ANALYSIS
BUCKLING ANALYSIS |
Dynamics and Kinematics and motion simulation:
|
Dynamics and
Kinematics and motion simulation:
EXAMPLE 1 (MOTOR)
EXAMPLE 2 (QRM) |
Ergonomy |
insert manikin – edit
placement – manipulation manikin – reach – reach envelop – apply
posture – look at
vision cones – RULA analysis – SNOOK
analysis – Carrying analysis
lifting and lowering analysis – pushing
and pulling analysis |
Manufacturing |
reference model –
workpiece – work center – operation – mill window – tool –
milling strategies
roughing – finishing – pocketing – volume
rough – profile milling – surface milling – drilling
automatic drilling – toolpath |
MOLD Design |
reference model –
automatic workpiece – silhouette curve – pull direction –
parting surface
ref part cutout – mold volume
MOLD ANALYSIS
material – gates – automatic gate creation
– analysis – result advisor – moldability melt front time
air trap – pressure – temperature –
maximum shear rate – frozen layer ratio – velocity vector – flow
rate
sprue pressure – clamping force
|
