Name : CATIA SIMULATION
Downloadable File
Size : 790 MB
File Type : RAR File
Time of Education : 73
min |
| Generative
Structural Analysis |
INTRODUCTION
: simple static analysis – apply material – restraints – clamp –
sliders – user define restraints
loads – pressure – distributed force –
moment – bearing loads – line force density – enforced
displacement
OCTREE tetrahedron mesher – OCTREE
triangle mesher – 2d property – 3d property – deformation – von
mises stress
displacement – principal stress – slider
connection property – rigid connection property – virtual bolt
FREQUENCY ANALYSIS
BUCKLING ANALYSIS
SURFACE ANALYSIS
ASSEMBLY ANALYSIS |
| Digital Mockup |
EXAMPLE 1 (ENGINE)
EXAMPLE 2 (QUICK RETURN MECHANISM) |
| Ergonomic
Design and Analysis |
human builder – insert
a new manikin – IK behaviors – vision window – reach envelope
POSTURE – posture editor – forward
kinematics – reach – place mode – standard pose
HME Human Measurements Editor – Human
Activity Analysis |
