| Info |
Product
Name : CATIA BASIC
Downloadable File
Size : 2.2 GB
File Type : RAR File
Time of Education : 287
min |
| Intro |
how to start – menu – customization – mouse
buttons – shortcuts |
| Sketcher |
profile – rectangle –
corner rectangle – center rectangle – parallelogram – elongated
hole – keyhole profile
hexagone – circle – arc – ellipse –
parabola – hyperbola – conic – spline – connect – line – axis –
point
corner – chamfer – trim – break – quick
trim – close arc – complement – mirror – symmetry – translate –
rotate
scale – offset – project 3d elements –
intersect 3d elements – project 3d silhouette edge – constraints
geometrical constraints – dimensional
constraints |
| Part Design |
sketch based
features : pad – pocket – drafted filleted pad –
drafted filleted pocket – shaft – groove – hole – rib – slot
stiffener – multisection solid – removed
multi section solid – multi pad – multi pocket – solid combine
Dress up features : edge
fillet – variable fillet – face face fillet – chordal fillet –
tritangent fillet – chamfer
draft – variable angle draft – shell –
thickness – thread / tap – remove face – replace face
Surface based feature :
split – thick surface – close surface – sew surface
Transformation features :
translation – rotation – symmetry – mirror – rectangular pattern
– circular pattern
user pattern – scaling – affinity
Boolean operation : add –
remove – intersect – union
reference
elements : point – line – plane
formula |
| Sheet Metal |
wall – wall on edge –
extrusion – hopper – rolled wall – bend – conical bend –
unfolding – folding – cutout
circular cutout – hole – corner relief –
corner – chamfer – surface stamp – bead – curve stamp – louver
bridge – dowel – transformation commands |
| Assembly &
Drafting |
component – product –
part – existing component – manipulation – snap – explode stop
manipulation on clash
coincident constraint – contact constraint
– offset constraint – angle constraint – fix constraint – fix
together |
| Examples |
simple example 1
simple example 2
example 3 – propeller
example 4 – piston
example 5 – Quick Return Mechanism
example 6 – motor assembly |
